When
you invest in a Puget Systems workstation, we spend considerable effort making
sure that you are getting the best possible system for your workflow. And yet,
even the most powerful workstations we can produce sometimes struggle with one
of the most common codecs: H.264.
Is
it the fault of the hardware? Are Adobe or Black magic developers just bad at
optimizing their software? The answer is really neither. Instead, it comes down
to the fundamentals of how H.264 works that makes it such a difficult codec to
edit with.
HDMI
Encoder Modulator,16in1 Digital Headend, HD RF Modulator at Soukacatv.com
Why is H.264 hard to
edit?
In
this post, we are going to keep things at a bit of a basic level since H.264 is
extremely complex - especially once you start talking about different profiles,
GOP length, etc. If you want to get into those fine details, we recommend
reading the "Edit with" section of the Frame.io blog post How to
Choose the Right Codec for Every Project or Adobe's Encoding options for H.264
video post.
To
understand why H.264 is so hard to edit, it is important to understand how it
works. At its core, H.264 - also known as MPEG-4 AVC - is what is called an
Inter-frame or Long GOP (group of pictures) codec. Unlike Intra-frame codecs
like ProRes or DNx where each frame is self-contained, with a Long GOP codec
(like H.264 or even H.265) the majority of the frames only record what has
changed since the last frame.
SKD3013 3 Channel HD Encode Modulator
Dual HD Input Modulator With ISDB-T And DVB-T Modulation
DVB-T And ISDB-T Encoder Modulator
What is encoded in a
H.264 file
In
the image above, we are showing a simplified example of a red ball falling in
front of a blue background. What would display on your screen if you were to
watch this 5 frame video is exactly what you would expect. But if you could
examine the actual frame-by-frame information in the encoded H.264 video file,
what you would find is that the first frame looks normal, but the other frames
would only include what has changed since that first frame. In this case, since
the background is static, H.264 simply ignores it completely in order to reduce
the final file size of the video. The end result is a video format that can
pack a ton of information into a small file size, but requires additional
processing power to decode.
The
way H.264 does this is by separating your video into groups of frames with each
frame becoming either an I-, P-, or B-frame.
I-frames
are used at the start of each group and is often called the "key
frame". It is completely self-sufficient and acts as a reference frame for
the rest of the group.
P-frames
contain only what has changed since either the last I-frame or the last P-frame
(if there is one).
B-frames
are similar to P-frames except that they can either look back to the previous
I/P-frame or they can look forward to the next I/P-frame.
These
groups can range in size from just one frame long (referred to as
"All-I" since every frame has to be an I-frame), to hundreds of
frames in length. The longer the group, the smaller the file size, but the
harder it is to decode.
H.264 I-Frame, P-Frame,
and B-Frame decoding
In
the example above, let's assume you have a GOP length of 9 frames. If you
wanted to view frame 5 (which is a B-frame), the software first has to go to
the closest P-frame, then follow a trail of P-frames (just one in this case) to
get to the previous I-frame. At that point, it finally has all the information
needed to actually turn frame 5 into a full image. Remember that this is very
simplified example - these groups can be hundreds of frames long which results
in dozens of jumps between B-,P-, and I-frames.
If
you are watching an H.264 video in a normal video player, this isn't too big of
a deal since the player knows that you are just going to watch the video at
normal speed. Video editing, however, is much more complicated. Not only do you
often jump around the video to random frames, but you can also play both
backwards and forwards and at different speeds. Plus, it isn't good enough for
the editing software to just display what has changed since the last I-frame,
it has to completely render out each frame from scratch in order to properly
apply effects like color correction.
Intra-frame
codecs (such as ProRes, DNx, or even RAW) do not have this additional overhead
since each frame is completely independent. The bitrate and file size may be
much larger with ProRes versus H.264, but the overall load on your system is
much, much less.
VFR - Variable Frame
Rate
While
not directly related to how H.264 works, many people also deal with especially
poor performance due to what is called VFR or variable frame rate recording.
This is a feature offered on some phones, drones, and other devices that allow
it to dynamically reduce the frame rate of the recording if there is not much
movement in the scene. This can drastically reduce the file size in some cases,
but unfortunately, almost every editing software struggles with VFR.
The
end result is a compounding of issues - your system will already struggle with
H.264, then you are also throwing a variable frame rate at it. If this is an
option on your recording device, we highly recommend disabling it. If you
cannot do that, you should always transcode the footage so that it has a fixed
frame rate before editing. Even if you just transcode to a fixed frame rate
version of H.264, it should greatly improve editing performance. If you still
have issues, then try one of the solutions listed in the next section.
How can you improve
H.264 editing performance?
Since
the issue with H.264 is due to how it works on a fundamental level, there is
not an easy solution. Many video editing software has features for
"Hardware accelerated H.264 decoding", but in our experience they are
a mixed bag. The accelerated feature in DaVinci Resolve Studio seems to make at
least a small difference, whereas a similar feature in Premiere Pro doesn't do
much of anything from what we have seen.
In most cases, you only
have a couple of options:
1) Get a more powerful
computer
This
is obviously a brute force solution that isn't always the right choice. If you
are working on a laptop or low-end desktop, however, this may be a real option.
Keep in mind that even the most powerful systems available today will struggle
with higher bitrate H.264 media, so there is a limit to how effective this will
be.
2) Don’t record with
H.264
Another
obvious solution, but somewhat limited. Many cameras only offer H.264 as a
recording option and if storage space is a concern you may not be able to
afford jumping up to ProRes even if your camera has the ability to do so.
3) Transcode your
footage to an intermediate codec before editing
This
is similar to simply not recording with H.264, but at least removes the need to
have a camera that supports ProRes or other Intra-frame codecs. While
transcoding your footage to an intermediate codec like ProRes or DNx before
editing should solve most performance issues (or at least greatly improve
them), the downside is that you will still have to store the larger files that
are the result of moving to a non-Long GOP codec. In addition, you have to wait
for your files to transcode before you can begin editing.
There
are a huge number of software packages that can be used for transcoding, but
the two most popular tend to be Adobe Media Encoder and FFmpeg. If you decide
to use Media Encoder, you might consider setting up a watch folder that will
automatically transcode any footage you drop into that folder in order to
streamline the process.
4) Adopt a proxy
workflow
Proxies
are not a new feature in most video editing applications, but in recent years
they have become much, much easier to use. In a nutshell, proxies allow you to
easily toggle between the original footage and a light-weight version that is
optimized for editing. The advantage here is that you can use your original
files when you need the best visual quality (color grading, masking, exporting,
etc.), but switch over to the proxy when trimming or assembling your timeline.
In
addition, with most editing applications these proxy files can be generated in
the background and will auto-attach as they complete. The benefit here is that
you can start your editing immediately, and as the proxies are automatically
generated and attached you will simply notice a big improvement in playback and
scrubbing performance. In fact, since you rarely need high quality video while
trimming, you can reduce the resolution and quality of the proxies so that they
are super quick to generate, minimizing the impact on your editing process.
This
is becoming a common enough workflow that some high-end cameras even have the
option to record lower-quality proxy files on the fly. Not to worry if you
don't have that option, however, most editing software can either do it during
ingest or you can manually tell it to generate and attach a proxy with the
click of a button. While the process is different in every software
application, here are a few guides to get you started:
How
to use Proxy Files to Edit SUPER FAST in Premiere Pro!
Faster
Resolve Editing Using Optimized Media - DaVinci Resolve 12.5 Tutorial (applies
to newer versions as well).
Whether
your system will struggle with H.264 media or not depends on a wide range of
factors including what software you are using, how powerful your system is, and
the bitrate and other settings used to create your H.264 media. You may never
run into any issues, or your system may chunk along since you are trying to
work with 4K 150mbps H.264 media. If you are having issues, however, hopefully
this post has given you an idea of why H.264 is not considered an editing codec
as well as giving you a number of solutions to help improve your editing
experience.
